10–20 kVA UPS, Three-Phase Five-Wire and Single-Phase Three-Wire — High-Frequency Tower-Style Power Supply Series
Price range: ¥19,785.00 through ¥31,065.00
Input
- Wiring Mode: Three Phase Five Wire
- Rated Voltage: 360/380/398/415VAC
- Voltage Range: 190~520VAC
- Frequency Range: 50/60Hz±6Hz
- Power Factor ≥0.94
Output
- Wiring Mode: Single Phase Three Wire
- Rated Voltage: 208/220/230/240VAC
- Power Factor: Main Inverter: 1.0 Battery Inverter: 0.8(16-17 Cells)/0.9(18-19 Cells)/1.0(20 Cells)
- Voltage Accuracy ±1%
- Frequency Online Mode: Follow Mains Frequency, Battery Mode: (50/60±0.1%) Hz
- Voltage Harmonic: ≤3% (Resistive Load), ≤5% (Non-linear Load)
- Overall Efficiency > 95.0%
- Overload Capacity: Mains Mode: Load≤110%, 30min; ≤130%, 10min; ≤150%, 30s; >150%, 200ms Battery Mode: Load≤110%, 10min; ≤130%, 1min; ≤150%, 10s; >150%, 200ms
Battery
- Battery Cells: 16~20 (Default 16)
- Charging Current Default 1A, 1~12A Adjustable
- Transfer Time:Mains to Battery 0ms, Mains to Bypass 0ms
Environment
- Operating Temperature: 0°C~40°C
- Storage Temperature: -15°C~60°C (Without Battery)
- Humidity Range: 20~95% (Non-condensing)
- Operating Altitude: < 1000m
Other
- Communication Interface RS232, USB, SNMP (Optional), RS485 (Optional), Dry Contact (Optional), EPO (Optional)
Environmentally Friendly
- Wide voltage input range (110 VAC–300 VAC) and frequency range, ensuring strong adaptability to the power grid
- ECO operating mode delivers high efficiency and energy savings, reducing operating costs for users
Comprehensive Protection
- Self-diagnostic function upon startup; immediate audible and visual alarms when a fault is detected
- Features include output overload, output short circuit, inverter over-temperature, low battery voltage warning, and battery overcharge protection
Intelligent Management
- Supports RS232/USB communication; optional SNMP card, Modbus card, or dry contact card
- Configurable charging current; automatic, seamless switching between constant-current, constant-voltage, and float charging modes
| Weight | N/A |
|---|---|
| Dimensions | N/A |
| Capacity | 10KVA, 15KVA, 20KVA |
